Slide Rail Pile Chamber
Slide Rail Pile chamber boxes are a fast and economical shoring solution for inner-city projects with complex crossing services and sewers. The pile chamber serves as guidance and support for the trench sheets.
The application is easy to install in narrow site conditions, whereby the excavator can be located in front of the trench and carry out the dual operation of excavation and sheet placement. Alternatively, the sheet installation can take place by means of hammering equipment as required.
Pile chamber plates can be combined with any other Westport shoring system, including the Rolling strut system. This compatibility offers numerous economic advantages and flexibility when utilising existing elements of the Westport shoring family on-site.
Please contact us for further information or to make use of our in-house engineering design services.
TECHNICAL INFORMATION
Panel Range
| PANEL LENGTH - L(m) | PANEL HEIGHT - H(m) | PANEL THICKNESS tPL (mm) | INTERNAL BETWEEN ROLLING STRUT (m) | EXTERNAL LS (m) | MAX. PERM. EARTH PRESSURE (kN/m2) | WEIGHT (kg) |
|---|---|---|---|---|---|---|
| 2.0 | 2.4 | 107 | 1.8 | 2.77 | 158.2 | 550 |
| 1.4 | 355 | |||||
| 2.5 | 2.4 | 2.3 | 2.77 | 101.2 | 650 | |
| 1.4 | 420 | |||||
| 3.0 | 2.4 | 2.8 | 3.27 | 70.3 | 770 | |
| 1.4 | 495 | |||||
| 3.5 | 2.4 | 3.3 | 3.77 | 51.6 | 900 | |
| 1.4 | 580 | |||||
| 4.0 | 2.4 | 130 | 3.8 | 4.27 | 82.1 | 1370 |
| 1.4 | 880 | |||||
| 4.5 | 2.4 | 4.3 | 4.77 | 64.9 | 1530 | |
| 1.4 | 980 | |||||
| 5.0 | 2.4 | 4.8 | 5.27 | 52.6 | 1690 | |
| 1.4 | 1070 | |||||
| 5.5 | 2.4 | 5.3 | 5.77 | 43.4 | 1850 | |
| 1.4 | 1170 | |||||
| 6.0 | 2.4 | 5.8 | 6.27 | 36.5 | 2210 | |
| 1.4 | 1370 | |||||
| 6.5 | 2.4 | 150 | 6.3 | 6.77 | 36.5 | 2581 |
| 1.4 | 1620 | |||||
| 7.0 | 2.4 | 6.8 | 7.27 | 36.5 | 2780 | |
| 1.4 | 1744 | |||||
| 8.0 | 2.4 | 170 | 7.8 | 8.27 | 35.2 | 4000 |
| 1.4 | 2500 |
Corner Rail
| DESIGNATION | RAIL LENGTH L T (m) | WEIGHT PER RAIL (kg) | MAX. PERM. BEND. MOMENT (kNm) |
|---|---|---|---|
| SINGLE - SERIES 790 | 3.5 | 390 | 132 |
| 4-SIDED CORNER RAIL | 4.0 | 880 |
